Product Description

Our professionally managed organization is engaged in manufacturing, exporting and supplying an entire range of ESR Analyser. Widely used in hospitals and laboratories, the offered analyser is designed to measure chemicals in various biological samples. With utmost precision, the provided analyser is manufactured by utilizing optimum quality components and contemporary technology in compliance with industry standards. Furthermore, this ESR Analyser is defect free and can be availed by clients in both standard and customized specifications at affordable rates.


  • Easy installation
  • Compact design
  • User friendly operation
  • Precisely designed


ESR Analyser Our all products having in product quality accreditation like ISO-9001,ISO-14001,ISO- 13485,CE,WHO-GMP & FDA


  • Infrared optical detection technology.
  • Automatically scanning blood cells and location of the plasma interface from time to time with accurate positioning.
  • Internal thermal printer, ESR curve display and printout
  • Automatically amending the ESR results under the detecting temperature (15ºC ~32 ºC) to the ESR values at 18 C closely related with westergren results.
  • The results are not interfered by pharmacological samples such as jaundice, hemolysis or chyle

Measuring principal

Infrared barrier

Measuring time

30 minutes

Measuring precision

<0.2 mm


<0.3 %

Temperature Precision

< 0.3 ºC

Sample Volume

< 1.6 ml whole blood anticoagulant

Reading Channel



LCD screen with backlight RS-232 serial port


Internal thermal recorder

Operation Conditions

Temperature 15ºC ~32 ºC/ Humidity 85%

Power supply

AC22V/110V 10%, 50/60 Hz


320mm x 260 mm x 158 mm (LxWXH

Net Weight

5 kg
