Ultra Low Temperature Deep Freezer (-80C

Ultra Low Temperature Deep Freezer (-80C
Ultra Low Temperature Deep Freezer (-80C
Send Inquiry
Product Code : 11
Brand Name : Haier
Price And Quantity
  • Minimum Order Quantity
  • 1 Box
  • Price Range
  • 600000.00 - 640000.00 INR
Product Specifications
  • Use
  • Preservation
  • Suitable For
  • Preservation at -40~-86 Degree Celsius
  • Material
  • CRCA Powder Coating & Inside MS
  • Product Type
  • Low Temperature Deep Freezer
  • Dimension(L*W*H)
  • 590*630*1310(mm) 23.3*24.8*51.6(in) Millimeter (mm)
  • Weight
  • 290/310(kg) 639.3/683.4(lbs) Kilograms (kg)
  • Power
  • 220~240 Volt (v)
  • Color Code
  • Off White
  • Application
  • Bio-Medical,Pharmaceutical
Product Description

Specifications

Technical Data

Type -86 ULT Freeer
Cabinet Type Upright
Climate Class N
Cooling Type Direct cooling
Defrost Mode Manual
Refrigerant HFC
Noise Lever (dB) 49

Performance

Cooling performance(℃) -86
Temperature Range(℃) -40~-86

Control

Controller Microprocessor
Display LED

Electrical Data

Power Supply(V/Hz) 220-240/50/208-230/60/115/60
Power(W) 1000             1000            1200
Electrical Current(A) 9                    5.5              18

Dimensions

Capacity(L/Cu.Ft) 486/17.1
Net/Gross Weight(approx) 290/310(kg)
639.3/683.4(lbs)
Interior Dimensions(W*D*H) 590*630*1310(mm)
23.3*24.8*51.6(in)
Exterior Dimensions(W*D*H) 945*900*1980(mm)
37.2*35.4*78.0(in)
Packing Dimensions(W*D*H) 995*995*2150(mm)
39.2*39.2*84.6(in)
Container load (20'/40'/40'H) 12/24/24

Functions

High/Low Temperature Y
Remote Alarm Y
Hot Condenser Y
Power Failure Y
High/Low Voltage Y
Sensor Error Y
Low Battery Y
High Ambient Temp Y
Door Ajar Y

Accessories

Caster Y
Foot Y
Test Hole Y
Shelves/Inner Doors 3/4
Temperature Recorder Optional
USB Interface Y
Rs232/485 Interface Optional
CO2 Backup System Optional
LN2 Backup System Optional
Racks And Boxes Optional

Racks & Boxes(Optional)
Rack Model   Rack Description   Rack Dimensions (W*D*H)   Q'ty of Racks   Q'ty of Boxes   Q'ty of Samples
9*9 box / 10*10 box
DCJ-54-A   2 inch stainless steel rack 5*4   139*544*287(mm)
5.5*21.4*11.3(in)		   16   320   25920/32000
DCJ-54-B   2 inch stainless steel drawer rack 5*4   140*554*289(mm)
5.5*21.8*11.4(in)		   16   320   25920/32000

CO2 Backup System

LN2 Backup System

Chart Recorder

Others

Certificate CE/UL
Trade Information
  • Payment Terms
  • Cheque
  • Delivery Time
  • 6-8 Week
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • 995*995*2150(mm) 39.2*39.2*84.6(in)
  • Main Export Market(s)
  • Asia
  • Main Domestic Market
  • All India
  • Certifications
  • CE
