Bacteriological Incubator

Bacteriological Incubator
Bacteriological Incubator
Send Inquiry
Product Code : 68
Brand Name : Bioline
Product Description

We have always strive to offer our client an excellent range of Bacteriological Incubator that is widely used for day to day bacteriological and culture tests performed in various laboratory applications. The offered incubator is manufactured from optimum quality of components as per defined market norms. Moreover, this incubator is tested on various quality parameters at our sound manufacturing division to ensure its flawlessness at clients end. Apart from this, our clients can avail this Bacteriological Incubator from us in at market leading price.

Features:

  • Sturdy construction

  • Excellent performance

  • Operational fluency

  • Low power consumption

Further Details:


Temperature Range : 10 °C to 60°C Accuracy : ± 0.5°C

Temperature Uniformity : ±1.0°C

Temperature Suitable for 18 -24°C, 20-25°C, 30-35°C, 35-37°C, 40-45°C & 55-60°C.

Construction

This unit has double walled chamber, with glass wool/PUF insulation. This unit has full-length inner glass door and outside metal door with magnetic gasket and lock. Forced air circulation for uniform temperature.
Intellligent Control System

Temperature Controller with Ethernet Communication

Heating System

Long lasting stainless steel tubular heaters with s.s. fins.

Sensor

Temperature transmitter 4-20mA used for measurement. Temperature in degree Celsius with 0.1°C resolution.

Cooling System

Hermitically sealed compressor coupled with evaporation coil and condenser, safe guarded by time delay circuit. CFC free refrigerant

Alarms

Audio and visual alarms are generated for temperature variation

Safety

The unit is provided with safety devices for temperature over shoot in case of malfunction.

The unit works on 230 Volts AC and 50Hz mains supply.



Selection Guide



Exterior M.S. Powder Coated  & Interior S.S.

Interior & Exterior S.S.

Capacity

Internal Dimension

External  Dimension

Weight (Kg)

Tray

Cuft.

Litres

HxWxD (mm)

HxWxD (mm)

Eqp

Shp

(mm)

Nos.

NEC108RTSI

NEC108RTSSI

8

200

600 x 600 x 600

1150 x 760 x 1045

200

275

560 x 560

2

NEC112RTSI

NEC112RTSSI

12

324

900 x 600 x 600

1450 x 760 x 1045

250

325

560 x 560

3

NEC116RTSI

NEC116RTSSI

16

430

1200 x 600 x 600

1795 x 760 x 1095

275

350

560 x 560

4

NEC121RTSI

NEC121RTSSI

21

600

1200 x 700 x 700

1795 x 860 x 1195

300

400

660 x 660

4

NEC128RTSI

NEC128RTSSI

28

800

1200 x 800 x 800

1795 x 960 x 1295

325

425

760 x 760

4

NEC134RTSI

NEC134RTSSI

34

1000

1500 x 800 x 800

2095 x 960 x 1295

350

450

760 x 760

5

Eqp - Equipment
Shp – Shipping

Optional



  • Common Software: Chambers are connected on TCP/IP (Ethernet) with the centralized work station and transferring data in database. This centralized workstation provides the tool for viewing, trending and alarm management of chambers. It has date and time stamp audit trails and complies to US FDA 21 CFR Part 11.
  • Temperature Scanner: 4 point scanner for temperature having 4 temperature probes provided with alarms to monitor various parts of equipment.
  • Door Access System: The door access system restricts access to the chamber to authorized persons only. In this system a physical lock is provided additional to this password access control is provided. Maximum six users can access the chamber.
  • Remote Alarm System: Alarm for Temperature & Humidity deviations. Indicator LED to identify equipment deviation. Alarm hooter test push button.
  • Mobile Alert System Suitable for Newtronic Equipments whenever the alarm is generated by the system the user has to acknowledge the alarm with in predetermined time. If the user fails to acknowledge the alarm will send as a sms to 6 predefined numbers.
